Two-Story Modular Office Building Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Two-Story Modular Container Office Building |
| Construction Method | Prefabricated Modular Construction |
| Structural System | Weather-Resistant Steel Structure |
| Wall Panels | 50 mm EPS or Rock Wool Sandwich Panels |
| Roof Insulation | Glass Wool Insulation Panels |
| Roof Covering | Steel Roof Tiles |
| Ceiling | Steel Ceiling Panels |
| Windows | Single-Opening UPVC Windows |
| Doors | Steel Doors |
| Flooring | MGO Fireproof Boards |
| Functional Areas | Offices, Conference Room, Fitness Room, Shower Room, Restrooms, Lounge Area, Staircase, and Kitchenette |
| Installation | Factory Prefabrication and On-Site Assembly |
| Application | Construction Projects, Industrial Facilities, Mining and Energy Projects, Infrastructure Projects, Commercial Developments, and Institutional Projects |
The technical specifications of this two-story modular office building can be adjusted according to project requirements, local climate conditions, building regulations, and intended use. Materials, finishes, building systems, and functional layouts can be customized during the design and engineering stage.
Two-Story Modular Office Building Floor Plan
The floor plan is designed to combine office, meeting, sanitary, fitness, and staff facilities within a two-story modular office building. The layout shown below includes functional spaces for work, meetings, recreation, restrooms, and daily staff use.
| Overall Dimensions | |
|---|---|
| Specification | Value |
| Overall Footprint (Per Floor) | 12,030 mm (L) × 6,000 mm (W) |
| Floor Area | Approximately 72.36 m² per floor / 144.72 m² total |
| Building Configuration | Two Stories (Ground Floor + Upper Floor) |
| Standard Module Width | 3,000 mm per Module |
| Modules per Floor | 4 Modules |
| Ground Floor (1F) Room Dimensions | |
| Room / Area | Dimensions |
| Module 1 – Fitness Room | 3,000 mm × 6,000 mm |
| Module 2 – Shower Room | 3,000 mm × 2,865 mm, with a 2,000 mm Door Opening |
| Module 2 – Restroom | 3,000 mm × 2,865 mm, with Dual Fixtures |
| Module 3 – Conference Room | 3,000 mm × 4,730 mm, plus a 1,000 mm Entry/Circulation Zone |
| Module 4 – Staircase | 3,000 mm × 6,000 mm |
| Upper Floor (2F) Room Dimensions | |
| Room / Area | Dimensions |
| Module 1 – Private Office | 3,000 mm × 6,000 mm |
| Modules 2–3 – Open Conference / Lounge Area | 6,000 mm × 6,000 mm Combined |
| Module 4 – Staircase | 3,000 mm × 6,000 mm |
| Kitchenette Extension | 3,000 mm × 1,500 mm Rear Extension of the Staircase Module |
Cowinlife provides customized modular office building solutions. The modular container office floor plan can be customized to accommodate different office requirements, room configurations, staff facilities, and project-specific functions.
Two-Story Modular Office Building Features and Customization Options
Designed for projects that require more usable space and multiple supporting facilities within a limited footprint, this prefab office building combines multi-story construction, factory prefabrication, and flexible customization.
Two-Story Modular Design: The two-story configuration provides more usable space within a limited building footprint. The overall size, floor configuration, and internal layout can be adjusted according to project requirements.
Multi-Functional Interior: The prefabricated modular office can include private offices, meeting rooms, restrooms, fitness areas, and shared spaces to support a range of daily activities within a single facility.
Prefabricated for Efficient Assembly: All major components are prefabricated in the factory and assembled on site, helping to reduce on-site construction and support an efficient installation process.
Flexible Customization: The modular office building can be customized in terms of layout, dimensions, functional areas, interior finishes, and exterior design. The final design can be developed according to the intended use, number of occupants, site conditions, and specific project requirements.
The flexible layout and multi-functional design allow this type of modular office building to be used across a range of project environments. The prefabricated office building can be configured for temporary, semi-permanent, or permanent use depending on the structural design, materials, foundation conditions, local regulations, and project requirements.
Cowinlife: Modular Office Building Manufacturer
As an experienced modular office building manufacturer, Cowinlife develops customized solutions around the specific requirements of each project, including building layout, functional spaces, materials, interior configuration, and building services. From initial design coordination and factory manufacturing to quality inspection and project delivery, the production process supports consistent construction and efficient site assembly.
Need a Custom Two-Story Modular Office Building?
Whether you need a construction site office, an industrial project office, a multi-functional workspace, or a complete two-story modular building, Cowinlife can develop a solution tailored to your project requirements.
Contact Cowinlife to discuss your layout, functional requirements, and customized modular office building solution.
